AF-E 400 公用事業和工業自動化用電磁流量計 (2)

AF-E 400 公用事業和工業自動化用電磁流量計

Technical Data


Medium Liquid
Conductivity Down to 20 µS/cm
Flow Bidirectional
Measuring range DN6: 0.005…5 l/min ; DN15: 0.05…35 l/min;
DN20: 0.1…75 l/min ; DN25: 0.2…150 l/min
DN50: (2″) solution on request: 0.5…500 l/min
Measuring accuracy ±0.8 % MV ±0.2 % FS (up to +70°C/+158°F);
±1.5 % MV ±0.2 % FS (up to +90°C/+194°F)
Repeatability ±0.2 %
Nominal sizes DN6: 15; 20; 25 (¼”, ½”, ¾”, 1″)
DN40…50: (1½”…2”) solution on request
Nominal pressure 16 bar/232 psi
Process temperature -20…+90°C/-4…+194°F
Ambient temperature Up to +60°C/+140°F
Measuring Tube PEEK (glass fibre reinforced)
Electrodes Carbon PEEK
Wetted materials Stainless Steel 1.4404/316L, PEEK GF, Carbon. Internal gaskets EPDM or FKM.
Centellen gasket supplied with G connection type
Housing materials Stainless Steel 1.4404/316L,(housing)
ULTEM, PBT, PC-GF30 (face plate, buttons)
Protection class IP 65, 67
Weight less than 750 gram
Connection G male, NPT female, Rc female
Dimensions hxwxl 73 x 48 x 110mm
Power supply 24 VDC
Signal output 4…20 mA, frequency, pulse switch, IO link OR 2x 4…20 mA or Modbus
Inlets and Outlets 0D/0D
Approvals KTW, ACS, Reg 31, cULus

LDS 管道洩漏檢測

液體和氣體管線的洩漏檢測和定位

PipePatrol”極其迅速準確地檢漏,並確定管路中的洩漏部位。

採用兩種不同的方法: 統計品質平衡(SMB)以及擴展的即時瞬態建模(E-RTTM)。

對於以下應用,科隆公司的“PipePatrol”是理想的選擇:
